SEAT BELT AND AIR BAG
8-19
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
AIR BAG
The air bag Supplemental Restraint System (SRS) can provide additional protection for the
driver and passenger in the event of a collision.
Side Curtain Air Bag* (ACTYON)
The side curtain air bags are contained between right above
the front and rear doors and the end of the vehicle roof. The
side curtain air bag is designed to inflate only in an impact
to the side of the vehicle and protect occupants’ heads.
Pretensioner
(for Front Seat)*
When a severe frontal impact
occurs, seat belt pretensioners re-
wind the seat belts immediately to
restrain the occupants to their
seats. It helps the effective opera-
tion of the seat belts and airbags.
If this lamp does not go out after engine starting or comes on while driving, it means that
there is a malfunction in the system. Have the air bag system checked immediately by a
Ssangyong Dealer or Ssangyong Authorized Service Center.
Air Bag Warning Light
Driver’s Air Bag
The driver’s air bag is
located at center of the
steering wheel.
Passenger’s Air Bag*
The front passenger’s air bag
is located on the dashboard.
Pretensioner Activation
The seat belt pretensioners
remove slack from the
driver and passenger front
seat belts during a frontal
impact.
Load Limiter Activation
Immediately after a
collision, they loose the
belts to prevent from in-
juring the body from the
belt’s pressure.
