IN CASE OF EMERGENCY
12-27
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Maximum Load Limits (unit: kg)
In higher elevations the engine output and gradability may drop so
that it may not be possible for the permissible trailer loads to be
fully utilized in mountainous territory.
So, the permissible trailer loads should be reduced by 10% at
every 1,000 m after reached at 1,000 m of altitude.
WARNING
The above dimensions are certified data to meet the follow-
ing conditions.
Gradients up to 12%: Capable of 5 starts within 5 minutes
(with trailer)
Gradients up to 18%: Capable of 5 starts within 5 minutes
(without trailer)
2WD
4WD
Maximum
Trailer
Maximum permissible
static vertical load on
the coupling device
with brake
without brake
with brake
without brake
Type
MT
AT
MT
AT
2,100
2,300
750
2,100
2,300
750
2,300
750
92
ACTYON
ACTYON
SPORTS
with brake
without brake
Never exceed the maximum load limits of trailer or trailer towing
equipment and be aware that due to the higher load overheating
might occur in hot days or during continuous uphill driving.
WARNING
TRAILER BRAKES
If the trailer brakes are used, you should follow all instruc-
tions provided by the manufacturer. Never modify the brake
system of your vehicle.
TRAILER LIGHTS
Make sure your trailer is equipped with lights which meet
country and local requirements.
Always check for the proper operation of all trailer lights be-
fore you start to tow.
TIRES
When towing trailers, be sure your tires are properly inflated
to the inflation pressure.
Incorrect loading and crosswinds, large trucks passing or road
roughness can cause swaying or trailer separation.
• Adjust ball load by distribution of load in trailer.
• Check by weighing loaded trailer and ball load separately.
• Check the relevant state or territory registration authorities for
the legal maximum towing weight capacities.
WARNING
