SSANGYONG ACTYON - Page 291

LAMP
14-10
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
REAR FOG LIGHT (ACTYON)
1. Remove the ignition key from the
key cylinder.
2. Remove the one bolt of the rear fog
light and remove the bracket.
3. Remove the three bolts and re-
move the assembly of the rear fog
light from the rear bumper.
4. Remove the lamp housing by turn-
ing it from the assembly of the rear
fog light.
5. Remove the bulb.
6. Replace it with a new one.
7. Install in the reverse order of
removal.
Rear fog light*
