6.3.2 Flexible SWJ-DP pin assignment
After reset (SYSRESETn or PORESETn), all five pins used for the SWJ-DP are assigned as
dedicated pins immediately usable by the debugger host (note that the trace outputs are not
assigned except if explicitly programmed by the debugger host).
However, some of the JTAG pins shown in Table 9 can be configured to an alternate
function through the GPIOx_AFRx registers.
Table 9 shows the different possibilities to release some pins.
For more details, see the reference manual (Table 1), available from the STMicroelectronics
website www.st.com.
6.3.3 Internal pull-up and pull-down resistors on JTAG pins
The JTAG input pins must not be floating since they are directly connected to flip-flops to
control the debug mode features. Special care must be taken with the SWCLK/TCK pin that
is directly connected to the clock of some of these flip-flops.
Table 8. Debug port pin assignment
SWJ-DP pin name
JTAG debug port SW debug port Pin
assignmen
t
Type Description Type Debug assignment
JTMS/SWDIO I
JTAG test mode
selection
I/O
Serial wire data
input/output
PA13
JTCK/SWCLK I JTAG test clock I Serial wire clock PA14
JTDI I JTAG test data input - - PA15
JTDO/TRACESWO O JTAG test data output -
TRACESWO if async
trace is enabled
PB3
JNTRST I JTAG test nReset - - PB4
Table 9. SWJ I/O pin availability
Available Debug ports
SWJ I/O pin assigned
PA13 /
JTMS/
SWDIO
PA14 /
JTCK/
SWCLK
PA15 /
JTDI
PB3 /
JTDO
PB4/
JNTRST
Full SWJ (JTAG-DP + SW-DP) - reset state X X X X X
Full SWJ (JTAG-DP + SW-DP) but without
JNTRST
XXXX
JTAG-DP disabled and SW-DP enabled X X
JTAG-DP disabled and SW-DP disabled Released
