OmniaTap xs
basic
; Version August 2023
Subject to technical changes
Water can escape through leaks. Therefore, always make sure that the floor in the area
of the work surface is dry to avoid accidents caused by slipping.
Use the connection accessories to connect the OmniaTap xs system to the feed water connection and
to the free drain. Observe the requirements for the feed water (see technical data). Connect the
connection hose with integrated hat filter with its R3/4" internal thread to the house feed water
connection. Now plug the free end of the 8mm hose into the 8mm quick connector labelled "Inlet" on
the back of the system (see System Connections). Then connect the second 8mm hose to the "Drain"
device connection and guide the free end of the hose into a drain, through which the rinsing water can
drain without pressure. Connect the sterile tank overflow with an 8mm hose to the free drain as well.
Screw the sterile ventilation filter into the thread provided on the back, top left of the tank.
Finally, open the shut-off valve on the building's feed water connection. Check the hose connections
for leaks.
Remove the cover of the OmniaTap xs system and place the pretreatment cartridge in the right slot
and the ultrapure water cartridge in the left slot. Connect the cartridges with the quick-release
couplings by pushing them on. The quick-release fasteners must audibly click into place.
See the illustration:
cartridge
