10 Assembly
10.1 Operating environment
When selecting the installation location, observe the following requirements:
- The pressure of the feed water must be between 0.5 and 6 bar.
- The standing surface must be level.
- A suitable protective contact socket must be available for the electrical supply of the OmniaTap xs
system (see technical data).
- There must be sufficient free workspace for problem-free operation, maintenance and repairs.
- There must be sufficient space to operate the system.
- An on-site, lockable feed water connection with R¾" external thread is required.
The system is only intended for operation within an industrial environment. In other
environments, electromagnetic immunity cannot be guaranteed.
Temperatures below +2°C can damage the device due to frost!
The feed water pressure must be less than 6 bar, otherwise the system can be damaged!
If necessary, use a pressure reducer.
Make sure a free drain is available to avoid water damage!
A free outlet, primarily a funnel siphon DN 50, is to be provided for the rinsing water of
the OmniaTap xs system in the immediate vicinity of the location. The upper edge of the
outlet must not exceed a height of 300 mm above the level of the appliance in order to
ensure free outlet and thus flawless functionality of the drain. It must be ensured that the
flushing water line is neither closed nor throttled.
A DN 50 floor drain with free drainage is to be provided in the operating room. If there is
no floor drain, we recommend using a water monitor to prevent damage to the system
and equipment as well as the building.
10.2 Assembly
Set up the OmniaTap xs system at the operating site and make sure that the system is
standing securely. When transporting the system, never lift it by the dispenser arm, only
by the rear wall, bottom or side walls of the main body. See chapter "Transport and
packaging".
In order to protect the power pack from moisture, it must not be operated lying on the
table next to the device. Attach the power pack to a suitable wall near the device using
the bracket included in the scope of delivery.
