– 162 –
APPENDIX
■ DIP switch 1 Factory presetting: All ON
*1
SW Function ON OFF
1-1
Not used (Always ON)
1-2
Hand shaking (BUSY condition)
Receive buffer Recive
full or offline buffer full
1-3 Always ON Should be set on
1-4 Auto Cutter *1 Invalid Valid
1-5 Printing width *2
210 dots 200 dots
(420 half dots) (400 half dots)
1-6 Automatic status function *3 Invalid Valid
1-7 Should not be change (Should be set on)
1-8 Command emulation Star ESC/POS
*1.The factory settings for enabling/disabling the auto-cutter are as follows.
Models without auto-cutter (SP2300 Series): Invalid (Switch 1-4 = on)
Models with auto-cutter (SP2500 Series): Valid (Switch 1-4 = off)
Note: If the auto-cutter is valid on models without this function, a mechanical
error will occur. Do not enable.
*2 Total dot number for one line.
(This setting determines the default print range and number of digits as
follows.)
Switch 1-5 Print range ANK default digits (ANK 7 × 9/5 × 9)
ON 63 mm 42/35 digits
OFF 60 mm 40/33 digits
*3 Automatic status function: When valid, the status occurrence conditions are
as follows.
Star mode: All status occurrences enabled.
ESC/POS mode: Online/offline factors only. (Same conditions as <GS>a2).
To Next Page
