D-2. Serial Interface
Be sure to turn the power to both the printer and host computer off before
changing the setting of the DIP switches.
The following is the procedure for changing the settings on DIP switch No. 2.
1. Turn the power to both the printer and computer off.
2. Remove the 2 screws.
3. Remove the serial interface board unit.
4. Change the setting of the DIP switches.
Fig. D-2 DIP switch array
Fig. D-3 DIP switch 2
Power off
ON
OFF
DIP switch 2
ON
OFF
DIP switch 1
DIP switch 2
