SP2500 type
Fig. 3-2 External view of the printer (SP2500 type)
Cover
Protects the printer from dust and reduces noise.
Do not open the cover while printing.
Control panel
Features two control switches and two
indicators to indicate printer status.
AC adapter
Refer to the following
section for installation
instructions.
Interface connector
Connects the printer with
host computer.
Peripheral unit drive circuit
connector
Connects to peripheral units
such as cash drawers, etc.
Do not connect this to a
telephone.
DIP switch
Use to make various
settings.
Power switch
Turns printer power on
and off.
