WIRING THE CONNECTOR JUNCTION BOX (P1 & P2 PLUG TO 16 WIRE CONTROL CABLE)
BLACK
RED
GREEN
WHITE
BROWN
BLUE
ORANGE
YELLOW
VIOLET
GREY
PINK
CRÈME
WHITE WITH ORANGE STRIPE
SHIELD WIRE
16 WIRE CONTROL CABLE
1

2

3

4

5

6

7

8

9

10

11

12

13

S

P1 PLUG
(LOCATED INSIDE CONNECTOR BOX)
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
WHITE WITH RED STRIPE
WHITE WITH BLACK STRIPE
WHITE WITH GREEN STRIPE
NOT USED
16 WIRE CONTROL CABLE

14

15

16

17

18

19

20

21

22

23

24

25
P2 PLUG
(LOCATED INSIDE CONNECTOR BOX)
FIG. 5.15
