INSTALLATION
Commissioning
www.stiebel-eltron.com WPF basic | 41
11.7 WPMiw commissioning report
No. Parameter Setting range Standard System value
1 Enter code 0000 to 9999 1000
2 Language German
3 Contrast -10 to +10 0
4 Display Actual return
5 Emergency mode ON / OFF OFF
6 Cooling mode ON / OFF OFF
7 Heat-up program ON / OFF OFF
8 Summer mode ON / OFF ON
9 Pump cycles ON / OFF OFF
10 Buffer primary pump – constant run ON / OFF ON
11 SET FIXED VALUE OFF / °C OFF
12 Source Ethylene glycol
13 MIN source temperature -10 °C to 10 °C -9 °C
14 Maximum return temperature 20 °C to 55 °C 50 °C
15 Maximum heating flow temperature 20 °C to 65 °C 60 °C
16 HP sensor 38 bar to 40 bar 38 bar
17 Maximum mixer temperature 20 °C to 90 °C 50 °C
18 Mixer dynamic 30 - 240 100
19 Frost protection -10 °C to 10 °C 4 °C
20 Select remote control Heating circuit 1
21 FE correction -5 K to +5 K 0
22 Room influence 0 to 20 5
23 Temperature limit, heating OFF to 30 °C OFF
24 Dual mode temperature, heat source 2 -20 °C to 30 °C -20 °C
25 Temperature limit, DHW OFF to 30 °C OFF
26 Dual mode temperature, DHW -20 °C to 30 °C -20 °C
27 DHW eco ON / OFF OFF
28 DHW hysteresis 1 °C to 10 °C 3 °C
29 DHW correction 1 K to 5 K 3 K
30 Pasteurisation ON / OFF OFF
31 Controller dynamics 1 – 30 20
32 Idle time after switching the compressor OFF 1 to 120 min 20 min
33 Remaining idle time
34 Single phase ON / OFF OFF
35 Quick start
36 Relay test
37 LCD test
38 Fault list
39 WPMiw software issue
40 Analysis
41 Diagnosis
42 Heat pump reset
43 Runtimes
