15.15 Datentabelle WPF 5-10 S basic
Output details apply to new appliances with clean heat exchangers.
The power consumption figures for the integral auxiliary drives are maximum values and may vary subject to operating point.
The power consumption of the integral auxiliary drives is included in the output details of the heat pump (to EN 14511).
WPF 5 S basic WPF 7 S basic WPF 10 S basic
074425 074426 220819
Heating output
Heating output at B0/W35 (EN 14511) kW 5.80 7.80 9.90
Power consumption
Power consumption at B0/W35 (EN 14511) kW 1.35 1.78 2.20
Max. power consumption, circulation pump on the heating side W 93 93 93
Power consumption, emergency/booster heater kW 8.8 8.8 8.8
Coefficient of performance
COP at B0/W35 (EN 14511) 4.30 4.40 4.50
Sound emissions
Sound power level (EN 12102) dB(A) 46 47 51
Sound pressure level at a distance of 1m in a free field dB(A) 38 39 43
Sound pressure level at a distance of 5m in a free field dB(A) 38 39 43
Application limits
Max. permissible pressure MPa 0.3 0.3 0.3
Min. application limit on the heating side °C 15 15 15
Max. application limit on the heating side °C 60 60 60
Min. application limit, heat source °C -5 -5 -5
Max. application limit, heat source °C 20 20 20
Energy data
Energy efficiency class A+/A++ A+/A++ A+/A++
Electrical data
Frequency Hz 50 50 50
Control unit fuse/MCB A 1 x B 16 1 x B 16 1 x B 16
Compressor fuse/MCB A 1 x C16 1 x C 25 1 x C 25
MCB/fuse protection, emergency/booster heater A 1 x C 35 1 x C 35 1 x C 35
Rated voltage, control unit V 230 230 230
Rated voltage, compressor V 230 230 230
Rated voltage, emergency/booster heater V 230 230 230
Control unit phases 1/N/PE 1/N/PE 1/N/PE
Compressor phases 1/N/PE 1/N/PE 1/N/PE
Emergency/booster heater phases 1/N/PE 1/N/PE 1/N/PE
Starting current (with/without starting current limiter) A 29/58 32/88 41/97
Versions
Refrigerant R410 A R410 A R410 A
Refrigerant charge kg 1.6 2.0 2.6
CO
2
equivalent (CO
2
e) t 3.34 4.18 5.43
Global warming potential of the refrigerant (GWP100) 2088 2088 2088
Compressor oil Emkarate RL 32 3MAF Emkarate RL 32 3MAF Emkarate RL 32 3MAF
Evaporator material 1.4401/Cu 1.4401/Cu 1.4401/Cu
Condenser material 1.4401/Cu 1.4401/Cu 1.4401/Cu
Circulation pump type on the heating side Stratos PARA 25/1-7 Stratos PARA 25/1-7 Stratos PARA 25/1-7
Dimensions
Height mm 960 960 960
Width mm 510 510 510
Depth mm 680 680 680
Weight
Weight kg 107 113 120
Connections
Connection on the heating side G 1 1/4 G 1 1/4 G 1 1/4
Connection on the heat source side G 1 1/4 G 1 1/4 G 1 1/4
