Slipinstallingsleeve(1)
11298934600overtheend
ofthecrankshaft.
•
Slidetheoilseal(1),openside
facingthecrankcase,overthe
endofthecrankshaft.
•
Usethepresssleeve(2)
11148934601topressitfully
home.
-Fittheenginehousing.
-Installthestartercup.
Clutchside:
-Removetheflywheel-see6.2.
•
Applythepuller(1)
59108904400(withNo.3.1
jaws00008933706).
-Tensionthearms.
-Pullouttheoilseal.
Important:Takecarenotto
damagecrankshaftstub.
-Cleansealingsurfacewitha
standardsolvent-baseddegrea-
santcontainingnochlorinated
orhalogenatedhydrocarbons-
see11.2.
-Lubricatesealinglipsofoilseal
withgrease-see11.2.
•
Slidetheoilseal(1),openside
facingthecrankcase,overthe
installingsleeve.
•
Usethepresssleeve(2)
11208932400topressitfully
home.
-Fittheflywheel.
VA
232RA039
1
VA
232RA041
1
VA
232RA040
2
1
VA
232RA042
2
1
FS45 13

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
