7MS 201, MS 201 C, MS 201 T, MS 201 TC
Fastener Thread size For component Torque
Nm
Remarks
Screw M 4x16 Tank housing / crankcase 4.5 2) 4)
Screw M 5x43 Carburetor / handle housing, stage 1 0.8 5)
Screw M 5x43 Carburetor / handle housing, stage 2 3.0 5)
M 10x1 Spark plug / cylinder 12.0
Screw M 4x20 Ignition module / crankcase 4.0 3)
Screw M 5x20 Cylinder / crankcase 10.0 2) 4)
Remarks:
1) Loctite 272, high strength up to 250 °C (482 °F)
2) Screws with binding head
3) Micro-encapsulated screws
4) Waxed screws
5) Bright and waxed screws
6) Degrease crankshaft/flywheel and mount oil-free
Use the following procedure when refitting a DG or P screw in an existing thread:
Place the screw in the hole and rotate it counterclockwise until it drops down slightly.
Tighten the screw clockwise to the specified torque.
This procedure ensures that the screw engages properly in the existing thread and does not form a new thread
and weaken the assembly.
Before reinstalling a micro-encapsulated screw, clean both threads (screw tap into female thread by hand and
then blow out with compressed air, clean male thread with brush), coat clean screw with medium strength
Loctite 242 or 243.
Power screwdriver setting for polymer: DG and P screws max. 500 rpm
Do not use an impact wrench for releasing or tightening screws.
Do not mix up screws with and without binding heads.
