2.5 Tightening Torques
DG and P (Plastoform) screws are used in polymer and light metal components. These screws form a
permanent thread when they are installed for the first time. They can be removed and installed as often as
necessary without impairing the strength of the screwed assembly, providing the specified tightening torque is
observed.
For this reason it is essential to use a torque wrench.
Fastener Thread size For component Torque
Nm
Remarks
Screw M 4x12 Chain tensioner cover / crankcase 1.8 2) 4)
Screw M 4x16 Antivibration element on oil tank / crankcase 4.0 3)
Collar stud M 8 Collar stud for bar 22.0 1)
Screw P 4x14 Cover / chain sprocket cover 1.5
Screw M 4x12 Cover, oil pump / crankcase 2.0 2) 4)
Screw M 4x9.6 Spark arresting screen / muffler 2.0
Screw P 6x19 Handle housing / front handle (MS 201) 6.0
Screw P 6x19 Handle housing / front handle (MS 201 T) 3.5
Screw M 4x16 Handlebar / crankcase 4.0 3)
Screw P 4x14 Handle molding / handle housing 1.5
Screw P 6x19 Retainer, ring / tank housing 6.0
Screw P 4x10 Clamp, wiring harness / handle housing
(MS 201)
1.8
Screw P 4x10 Clamp, ignition lead 1.8
Screw M 5x16 Chain catcher / spiked bumper / crankcase 10.0 2) 4)
Screw M 5x16 Spiked bumper / crankcase 10.0 2) 4)
Screw M 4x12 Manifold / cylinder 3.0 2) 4)
Screw M 4x16 Crankcase, sprocket side/fan side 4.5 2) 4)
Screw P 5x16 Bearing plug / handle housing 3.0
Screw M 4x16 Fan housing / crankcase 4.0 2) 4)
Screw P 5x16 Fan housing / tank housing 4.0
Carrier M 8x1 L Carrier / crankshaft 25.0
Screw M 4x12 Oil pump / crankcase 3.5 2)
Screw P 5x29.5 Annular buffer / handle housing 3.0
Screw P 4x14 Annular buffer / tank housing 1.5
Screw P 4x10 Rewind spring retainer 1.5
Screw M 5x16 Muffler / cylinder, stage 1
(tightening first screw)
2.5 2) 3)
Screw M 5x16 Muffler / cylinder, stage 2
(tightening second screw)
10.0 2) 3)
Screw M 5x16 Muffler / cylinder, stage 3
(tightening first screw)
10.0 2) 3)
Collar stud M 5x18 Bar mounting / crankcase 7.0 2) 3)
Nut M 8x1 Flywheel / crankshaft 23.0 6)
Screw P 4x10 Insulating plate (MS 201) 1.5
