Datasheet for the platform tractor
DESIGNATION
1.1 Manufacturer KION
1.2 Model type LTX T 08
1.3
Method of propulsion: battery, diesel, petrol,
LPG, mains power
Battery
1.4
Driving: manual, pedestrian, standing, seated,
order picking
Seated
Towing capacity
(1)
t 6.2
(1)
1.5 Load capacity Q t 0.8
1.7 Rated drawbar pull F N 1240
1.9 Wheelbase y ±5 mm 1795
WEIGHT LTX T 08
2.1 Kerb weight (with cab) kg ±10% 1470
2.2 Axle load without load, front/rear (with cab) kg ±10% 740/730
(2)
2.1 Kerb weight (without cab) kg ±10% 1215
2.2 Axle load without load, front/rear (without cab) kg ±10% 580/635
(2)
2.2 Axle load with load, front/rear (with cab) kg ±10% 740/1530
(2)
2.2 Axle load with load, front/rear (without cab) kg ±10% 580/1435
(2)
WHEELS AND PNEUMATIC TYRES LTX T 08
3.1
Tyres, front/rear (SE = CS superelastic, P =
pneumatic)
SE
3.2 Tyre size, front 125/75 - 8
3.3 Tyre size, rear 125/75 - 8
3.5 Wheels, number front/rear (x = driven) 1/2 x
3.6 Track width, front b10 ±5 mm 0
3.7 Track width, rear b11 ±5 mm 860
DIMENSIONS LTX T 08
4.7 Height of the overhead guard with/without cab h6 ±5 mm 2070/2000
4.8 Seat/stand-on platform height h7 ±5 mm 1020
(4)
4.12 Tow coupling height h10 ±5 mm a) 1285 b) 340 c) 395
(4)
4.13 Platform height, without load h11 ±5 mm 645
(4)
4.16 Loading platform length (with and without cab) I3 ±5 mm 1275/1415
4.17 Rear overhang I5 ±5 mm 840
4.18 Loading platform width b9 ±5 mm 900
4.19 Overall length i1 ±5 mm 2955
4.21 Overall width b1 ±5 mm 1000
4.32 Ground clearance at centre of wheelbase m2 ±2 mm 135
Technical specifications
6
Datasheet for the transponder
166 1191 801 15 51 EN - 02/2021 - 10
