Driving the tow tractor
Definition of directions
Names used in the text: forward travel (1), re-
verse travel (3), to the right (2) and to the left
(4) refer to component installation position
with respect to the driver's compartment.
The load is positioned at the rear.
Tow tractor ignition using the key
WARNING
Risk of accident
Before switching the tow tractor on, all pre-commis-
sioning tests must be performed. There must be no
faults detected.
– Perform all tests before commissioning. See
chapter
Pre-commissioning checks and proce-
dures
.
– Do not operate the truck if faults have been identi-
fied!
– Contact the After-Sales Service Centre.
– Insert the switch key into the key switch (1).
– Turn clockwise to switch on.
All controls on the screen of the display unit
briefly switch on.
The truck is ready for operation.
Use
4
Driving the tow tractor
50 1191 801 15 51 EN - 02/2021 - 10
