Still R70-45T User Manual

Circuit diagrams 8
Electrical equipment
6H1
Coolant temperature light
6H2
Oil pressure warning light
6H3
Fuel level lamp
6H4
Glow filter indicator light
6H5
Air filter indicator light
6H6
Carbon brush indicator light for 1M1
6H7
Carbon brush indicator light for 1M2
6H8
Carbon brush indicator light for 2M1
6H9
Carbon brush indicator light for 3M1
6H10
General carbon brush indicator light
6H11
Brake fluid indicator light
6H12
Start indicator light
6H13
Catalytic converter indicator light
6H14
Motor blower indicator light
6H15
Engine temperature indicator light
6H16
Soot filter indicator light (gn)
6H17
Soot filter indicator light (rd)
6H18
Indicator light at 6 km/h
6H19
Mast vertical position indicator
6K1
Relay for oil pressure
6K2
Relay for oil pressure
6K3
Relay for coolant light
6K4
Relay for coolant light
6K5
Relay for hour meter
6P1
Operating hour meter
6P2
Operating hour meter
6P3
Discharge indicator
6P4 Milometer
6P5
Coolant temperature indicator
6P6
Oil temperature indicator
6P7
Oil pressure indicator
6P8 Fuel level indicator
6P9 Wheel base indicator
6P10
Speed indicator
6P11 Ammeter indicator
6P12
Discharge indicator/hour meter
6P13
Carbon brush wear indicator
6S1
Oil pressure warning switch
6S2 Air filter indicator switch
6S3
Oil pressure switch
6S4 Brake fluid switch
6S5
Motor blower monitoring switch
6S6
Engine temperature switch
6S7 Soot filter indicator switch
6S8
Reset switch for carbon brush wear
indicator
6S9 Oil filter switch
Special functions
7A1
Printed circuit board for parking brake
signal transmitter
7B1
Lift mast sensor
7F1 Fuse
7F2 Fuse
7H1
Indicator light for 1S3
7H2
Warning signal transmitter
7K1
Relay for warning signal
171673 [EN] 265
