Still R70-45T User Manual

8 Circuit diagrams
Electrical equipment
7K2
Emergency cut-off contactor
7K5
Dead man relay (lift)
7K6
Dead man relay (traction)
7K7
Relay for seat contact
7S1 Seat contact switch
7S2
Emergency switch
7S3
Battery locking switch
7S4
Temperature switch
7S5
Temperature switch
7S6
Temperature switch
7S7
Temperature switch
7S8
Temperature switch
7S9
Temperature switch
7S10
Temperature time switch
7S11
External start switch
7S12
Warning signal switch
7S13
Dead-man switch
7S14
Emergency start switch
7S15 Switch for solenoid valve
7V8
Diode for solenoid valve
7X1 Pilot contact
7X11
Connector for external start
7Y8
Left solenoid valve (fork carriage)
7Y9
Right solenoid valve (fork carriage)
Automated functions
not assigned
Miscellaneous
9A1
Control unit for ignition
9A2
Shut-down solenoid printed circuit
board
9A3 Jetronik control unit
9A4
Generator start/carbon brush monitor
printed circuit board
9A5
Lambda control system control unit
9A6
Protective circuit printed circuit board
9A7
2-pedal printed circuit board with
shut-down device
9A8
2-pedal printed circuit board with fuse
9A9
Soot burner control
9A10
Control unit heater
9B1
Thermocouple for soot burner
9B2
Temperature switch for heater
9C1
Capacitor
9E1
Spark plug
9E2
Spark plug
9E3
Spark plug
9E4
Spark plug
9E5
Spark plug
9E6
Spark plug
9E7
Spark plug
9E8
Spark plug
9E9
Ignition distributor
9E10 Heater blower
9E11
Defroster blower
9E12
Seat heater
9E13
Sheathed-element heater plug
9E14
Sheathed-element heater plug
266 171673 [EN]
