Still R70-45T User Manual

Circuit diagrams 8
Electrical equipment
9E15
Sheathed-element heater plug
9E16
Sheathed-element heater plug
9E17
Sheathed-element heater plug
9E18
Auxiliary heater
9E19
Passenger seat heater
9E20
Defroster blower
9E21
Cigar lighter
9E22
Sheathed-element heater plug for
soot burner
9F1
Fuse for lambda control system
9F2
Fuse for ignition
9F3
Fuse for charge controller
9F4
Fuse for starter
9F5
Fuse for 9E10
9F6
Fuse for sheathed-element heater
plugs
9F7
Fuse for seat heater
9F8
Fuse for radio
9F9 not used
9F10 not used
9F11 not used
9F12
Fuse for 12-volt starter
9F13
Fuse for soot burner
9F14
Fuse for soot burner
9F15
Fuse for soot burner
9F16
Fuse for 9K26
9F17
Fuse for defroster
9G2 Generator
9H1
Indicator light for 9S3
9H2
Generator indicator light
9H4
Indicator light for 9S4
9H5
GREEN soot burner indicator
9H6 RED soot burner alarm
9H7
Soot burner diagnostic LED
9H8
Soot burner signal transmitter
9K1 External start contactor
9K2
Relay for 9M1
9K3
Glow plug relay
9K4
Relay for ignition
9K5
Starter lockout relay
9K6
Starter lockout relay
9K7
Relay for 9E11
9K8
Auxiliary relay for diesel mode
9K9
Auxiliary relay for diesel mode
9K10
Charging contactor
9K11
Auxiliary relay for diesel mode
9K12
Auxiliary relay for diesel mode
9K13
Auxiliary relay for 1A2
9K14
Auxiliary relay for 1S9
9K15
Relay for 9E20
9K16
Relay for 9Y5
9K17
Relay for 9M5/9M6
9K18
Relay for S1
9K19
Relay for 9Y4
9K20
Relay for 9Y4
9K21
Relay for soot burner operating
indicator
9K22
Relay for soot burner operating
indicator
9K23
Relay for soot burner lock
9K24
Relay for soot burner starter lockout
9K25
Current regulator for sheathed-
element heater plug
171673 [EN] 267
