Still R70-45T User Manual

8 Circuit diagrams
Electrical equipment
9K26
Relay for 9H8
9K27
Relay for 9Y8
9L1
Throttle for charge controller
9M1
Starter
9M2
Wiper motor
9M3
Rear windscreen wiper motor
9M4
Defroster blower motor
9M5 Fan motor
9M6 Fan motor
9M7
Injection pump motor
9M8
Fuel pump
9M9
Control motor for lambda sensor
9M10 Windscreen washer motor
9M11 Rear window washer motor
9M12
Roof wiper motor
9M13
Blower for soot burner
9M14 not used
9M15 not used
9M16
Secondary fan elec. machine
9M17
ASM circulating pump
9R1
Rotational angle detector for control
motor
9R2
Series resistor for external start
system
9R3 Heater resistor
9R4 Heater resistor
9R5
Series resistor
9R6 Varistor
9R7
Series resistor
9R8
Series resistor for sheathed-element
heater plug
9R9
Series resistor for sheathed-element
heater plug
9R10
Series resistor for sheathed-element
heater plug
9R11 Series resistor
9R12 Series resistor
9R13 Resistor
9R15
Series resistor for sheathed-element
heater plug/soot burner
9S1
Wiper switch
9S2
Rear windscreen wiper switch
9S3 Switch for 9E10
9S4 Switch for seat heater
9S5
Switch for automatic charging
9S6
Temperature switch
9S7 Switch for 9E11
9S8 Left door contact switch
9S9
Right door contact switch
9S10 Switch for 9E20
9S11 Switch for soot filter
9S12
Bonnet switch
9S13 Switch for 9M12
9S14
Soot burner starting switch
9S15
Soot burner emergency cut-off
9T1
Ignition coil
9V1 Diode
9V2 Diode
9V3 Diode
9W1
Steering column slip ring
268 171673 [EN]
