Stinger HEIGH10+ - Specifications

®
®
stingersolutions.com
stingersolutions.com
48
49
General
Operating Voltage: 10.5VDC to 16VDC
Grounding system; Negative Ground
Max current consumption: 15A fused
Dimensions
Radio Module:
177.7 mm x 112.96 mm x 50 mm
(W x H x D)
Display:
247.2 mm x 180.56 mm x 36.19 mm
(W x H x D)
Display
10.1-inch Diagonal
16:10 aspect ratio
1280 x 800
Pixels: 1,024,000
Active area 216.96 (W) x 135.6 (H) mm
Operating Temperature (C) -20° to 70°
Audio
Load impedance: 4Ω nominal / 2Ω
allowable
Continuous power output:
18W x 4ch/4Ω 20Hz to 20KHz, 1%THD at
14.4V
Speaker level adjustment: 0-40 steps
Audio Preamp Output level: 4.5Vrms
typical, 7vrms maximum without
distortion.
Audio Preamp 8 Channels: Front 1 Left,
Front1 Right, Front 2 Left, Front 2 Right,
Rear Left, Rear Right, Subwoofer Left,
Subwoofer Right.
Equalizer: (15-band)
25Hz/40Hz/63Hz/100Hz/160Hz/250Hz/400
Hz/630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3K
Hz/10KHz/16KHz
Gain: ±6dB (0.5dB/step)
Crossover level: 10 steps
Front1 and Rear output:
HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160H
z/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass
Slope: 6dB, 12dB, 18dB
Level: 0-15,1db/step
Front2 output:
HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160H
z/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass
LPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160H
z/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass
Slope: 6dB, 12dB, 18dB
level: 0-15,1db/step
Subwoofer Pre-lineout: 4.5Vrms typical,
7vrms maximum without distortion
LPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160H
z/250Hz
Slope: 6dB, 12dB, 18dB
Gain: 0db to 15dB (1dB/step)
Subwoofer level: 0-15, 1db/Step
Phase: 0 or 180
Time Alignment for 8 channels: 0 to
133 steps for inches and 0-99 steps for
9.9ms
User Preset EQ: Rock, Hip-Hop,
Electronics, Jazz, Pop, Flat.
Source Gain: default 0db, -10 to 10
adjustable, 0.35db/Step.
Volume Settings: Main Volume, Phone
Volume, Navigation Volume, Voice
Volume, Ringtone Volume adjustable
separately.
SPECIFICATIONS
