7 Assembly and setting up
Checking protective devices
Protective device
Checking
Engaging rod(1)
Production setting
◆ Pull engaging rod to highest position and release.
The carriage pulls out.
The engaging rod is held by a magnet.
◆ Press engaging rod to bottom position (zero
position).
The carriage must be stopped immediately
Middle position
◆ Pull engaging rod to middle position and release.
The carriage pulls out.
The engaging rod is not held by a magnet, must
rath
er fall back to
the zero position.
The carriage must be stopped immediately
Covers (2)
◆ Pull engaging rod to highest position and release.
The carriage pulls out.
◆ Open cover.
The carriage must be stopped immed
iately
The engaging rod falls to zero position
simultaneously.
◆ Repeat this process for each cover.
Lateral safety doors
(3)
◆ Pull engaging rod to highest position and release.
The carriage pulls out.
◆ Open the safety door on the right-hand side of the
machine.
The carriage must be stop
ped immed
iately
The engaging rod falls to zero position
simultaneously.
◆ Repeat this process for the safety door on the left
side of the machine.
Main switch (4),
emergency stop
switch
◆ Pull engaging rod to highest position and release.
The carriage pulls out.
◆ Switch off main switch / emergency shutdown
switch (position "OFF")
The carriage must be stopped immed
iately
The engaging rod falls to zero position
simultaneously.
The machine must switch off
automatically
.
