Stoneridge SE5000 - Page 17

15
At a glance
Vehicle Unit (VU)
VU user interface Page
1
Display
Standard display 16
Main menu display 17
To display messages 62
To display warnings 66
To display malfunctions 67
2
Paper cassette
To create a printout 51
To insert/change a paper
roll
81
3
Driver 2 driver card
slot
To insert/withdraw the
driver 2 driver card
22
VU user interface Page
4
Driver 2 button
To open the driver 2 driver
card slot
23
To change activities for
driver 2
53
5
Driver 1 button
To open the driver 1 driver
card slot
23
To change activities for
driver 1
53
6
Enter button
To confirm entries -
To acknowledge
messages
66
To acknowledge
warnings
66
VU user interface Page
7
Down button
To decrease values -
To select options -
8
Up button
To increase values -
To select options -
9
Quit button
To cancel processes -
To return to the previous
display
-
10
Driver 1 driver card
slot
To insert/withdraw the
driver 1 driver card
23
