STONEX S9III Plus - Page 13

Stonex S9III Plus GNSS Receiver – User Manual 12
After the self-check procedure, the receiver will turn on and begin to work
normally.
How can you select the working mode?
- Insert the battery, then press and hold I key + F key: the receiver
will start.
- Keep pressed I key + F key until the all lights blink at the same
time (Fig. 2.17), then release the keys.
- Now every time you press F key, the STATIC/ROVER/BASE lights
will turn on in the corresponding order. You can select three
different red lights, each of them refers to one working mode.
Press I key when the chosen light is on and the receiver will restart into the
selected working mode. Summary of working modes:
Fig. 2.18 - S9III PLUS summary of working mode led
1. Static mode
2. Rover mode
3. Base mode
Fig. 2.17 - S9III PLUS, all led blinking at the same time
1
2
3
