Stonex S9III Plus GNSS Receiver – User Manual 41
FEC (forward error corrector): used primarily with radio protocol Satel. It
introduces the information that make more "robust" the radio message,
making it less susceptible to interference.
Scrambler: used mainly with Satel protocol.
Area: makes the receiver fully complaint with the rules of the geographical
area.
Power mode: Select the transmission power level, low is 0.5 Watt while high is
2 Watt.
Click on button “OK” to confirm your choice.
5.2.3.3. External
This option give us the possibility to use an external device, usually an external
UHF Radio or an external Bluetooth device connected by cable at lemo-5
connector.
If you select “External” and Click on “Settings”, a new form will open and in
this form you can insert the baud rate of the external device:
Fig. 5.18 - External radio baud rate
