STONEX S9III Plus - Page 59

Stonex S9III Plus GNSS Receiver – User Manual 58
Band
GSM/GPRS/EDGE:
850/900/1800/1900 MHz
WCDMA/HSDPA:
2100/1900/850 MHz
Output Power
GSM850，EGSM900：33 dBm(2W)
GSM1800，PCS1900：30 dBm(1W)
WCDMA：23 dBm
POWER SUPPLY
Battery
2500 mAh high capacity Lithium battery,
Voltage 7.2 V
Voltage
9 to 15 V DC external power input with
over-voltage protection
Working Time in Static Mode
(GPS+GLONASS)
7 hours
Working time in GSM RTK
(GPS+GLONASS)
6.5 hours5
Charge time
typically 5 hours
Power consumption
< 3.8 W
Remaining time battery light
blinking
1 hour
PHYSICAL SPECIFICATION
Weight
1.2 Kg with internal battery, radio
standard UHF antenna
Operating Temperature
-40°C to 65°C (-22°F to 140°F)
(internal radio TX 50°C)
Storage Temperature
-40°C to 80°C (-40°F to 176°F)
Waterproof/Dustproof
IP67. Protected from temporary
immersion to depth of 1 meter and
from 100% humidity
Shock Resistance
Designed to survive a 2 m pole drop
on concrete
Vibration
Vibration resistance
