41 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
What: the UV lamps used for curing models have a long, but limited, working life.
When: if needed
How:
• Loosen the screws at the side of the lamp and disconnect the cables from Spartan board.
• Remove the UV lamp assembly.
• Remove the UV reflector and insert a new one.
• Reassemble and connect the UV assembly.
UV Lamp Replacement
