18 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Nozzle Selection
• The direction of the short-pointed end of the tap of the nozzle selector valve determines which nozzle is activated.
Physical Description
Jet
Nozzle
Nozzle
Selector
Spray
Nozzle
