Installing the System Enclosures
Installing the System in a Cabinet 9-21
Installing the System Enclosures
After you have installed the shelf unit (and reinstalled the system backplane assembly
and the front panel), you must install the CPU-I/O enclosures and the bezel.
1. Install the CPU-I/O enclosures.
a. Place each CPU-I/O enclosure on a flat surface and pull down the two ejector
levers (number 1, shown in lower-left box in Figure 9-18).
If your shipment contains an operating system DVD, the
operating system and system software were installed in
one of the CPU-I/O enclosures at the factory. In this case,
install the CPU-I/O enclosure that contains the boot disk
(labeled “Boot”) in the top CPU-I/O slot.
b. With the ejector levers in the open (down) position, slide each CPU-I/O
enclosure into the shelf unit.
To avoid personal injury, lifting a CPU-I/O enclosure
requires two persons.
Pour éviter toute blessure, deux personnes sont requises
pour soulever le boîtier CPU-I/O.
