Operation and control
V 152 10 11 Rev.: END
5-5
Inserting the binding thread:
● Insert the free end of the binding
thread into the hole at the end of the
tape pull hook
Fig. 5-4: Hole at front end of tape pull hook
● Insert the tape pull hook into the
pressing shield's tape duct.
● Allow the tape pull hook to latch into
place.
Fig. 5-5: Tape pull hook in tape channel
● Pull the tape hanging out of the first
hole approx. 2 m out of the machine.
