Operation and control
V 152 10 11 Rev.: END
5-11
Information!
For loose and crumbling material, place a piece of cardboard that
roughly matches the area of the bale to be subsequently compressed,
into the press chamber first.
The press chamber may maximally be loaded up to the lower edge of
the pressing shield. Ensure that material is not protruding from the
pressing shield (may cause trouble when the door is closed).
Compressing bales
● Pull the loading flap forward out of the gate, then downwards and let the loading
flap latch into place again.
● Press the "Start" button on the control panel.
The pressing shield moves downwards to the lower end position or until reversal
through the pressure relief valve. It is then moved back to the upper end position.
● Open the loading (in the Quick Door Auto version the loading door opens
automatically)
● Repeat the loading and compressing procedure until the "Bale finished" indicator
lamp lights up and the pressing shield moves up or (for foil programme only)
comes to rest on the bale.
5.4.3
Finishing and tying up bales
Situation:
– the "Bale finished" signal lamp comes on.
– the set bale height has been reached, the bale is fully compressed
– the pressing shield remains in the bale (only for foil programme option), otherwise
the pressing shield moves up again.
