Operation and control
V 152 10 11 Rev.: END
5-10
Bild 5-7 Brackets on the chamber door
● The protruding wir eis attached
behind the brackets on the front of
the door as shown
5.4.2
Loading and compressing
Opening the loading flap:
Slide the loading flap using the handles
upwards until the catch (1) latches into
the door gates (2).
Fig. 5-10: Gate
Loading pressing chamber:
● Load the segregated material through the opened loading door into the press.
