22
Issued: 24.02.2005
STRIDER MX
Pull the clamping bolt (6) with the form
shim (8) out of the seat support (9).
➨
Removing the clamping
bolt
Adjusting the seat height:
Adjusting the seat height
Tools required:
2 x ring spanner, size 12 mm
Hold the clamping bolt (6) with a ring
spanner (size 12 mm) and unscrew the
self-locking nut (7) with the other ring
spanner (size 12 mm).
➨
Remove the rear panelling.➨
Press the locking device on the plug
and disconnect the electric cable
connecting plug (5) to the rear lights
and rear indicators.
➨
