Strider MX 4 - Working step summary; Removing the seat

55
Issued: 24.02.2005
STRIDER MX
Removing the seat
Lift the seat while pulling the seat lock
(3) out of the seat support (4).
➨
In just a few steps you can dismantle the
Strider down to the following components to
make it ready for transport:
1. Chassis
2. Batteries
3. Drive unit
4. Rear panelling
5. Seat unit
1. Remove the seat unit
2. Remove the rear panelling
3. Remove the batteries
4. Loosening the brake cable
5. Fold the tiller down
6. Disengage the drive unit from the chassis
14.3.1 Working step summary
14.3.2 Removing the seat
Tilt the backrest forwards.
First pull out the locking device (1) and
then fold the backrest forward (2).
➨
Tilt the backrest
forwards
Transporting the Strider
