58
Issued: 24.02.2005
STRIDER MX
Remove the frames (17) upwards from
the holding bolts (18) on the drive unit.
➨
Separating the chassis
NOTE
Use rear bumper as grip
to stowe the drive unit.
Open the clamping bolt clamping lever
(15) and fold the clamping bolt upwards.
➨
Unlocking the drive unit
Tilt drive unit to the rear onto the anti tip
wheels (16).
➨
Tilt the drive unit away
Transporting the Strider
