General Technical Description
3 — 4
02_0460_0802GB
1 12
4
5
6
7
11
9
10
5
6
8
3
View from front
Item
Designation
1 Air filter
2 Oil filler with oil dipstick
3 Compressor
4 Control cabinet
5 Drain valve
6 Pressure tank
7 Oil drain plug
8 ”Working pressure” handwheel
9 ”Tank pressure” gauge
10 Pressure-reducing valve
11 ”Working pressure” gauge
Continued next page
