Operation
6 7
05_0186_0802GB
You can perform the following work using a spray gun connected to
a
Strobot delivery pump:
Danger
The machine may be operated only with a pneumatic tool
connected!
Caution
Read the information provided by the manufacturer before
connecting ”pneumatic tool” accessories.
See also the documentation provided by the delivery pump
manufacturer.
" Connect the compressor.
" Connect the delivery line to the spray gun.
" Connect the air hose to the compressor and the spray gun.
See also the documentation provided by the delivery pump
manufacturer.
1 2
3
Different models available
Item Designation
1 Spray gun (depending on model)
2 Material lever (depending on model)
3 Air valve
Continued next page
6.5 Using the spray gun
