Transport, Set-up and Connection
4 — 7
04_0134_0802GB
Supply cables must be laid visibly, taking local conditions into consi-
d
eration, and secured against damage.
Danger
There is a danger of electric shock which may have lethal conse-
quences by:
– contact with electrical cables;
– contact with machines with electrical drives, if the electrical con-
nection has not been properly made or the supply cable is dama-
ged.
The machine must be connected to a separate feed point at the con-
struction site.
The following power sources are permissible as a special feed point:
-- Site power distribution point
-- Small site power distribution point
-- Protective distributor
-- Movable protective device
The machine is electrically ready for service once the mains plug is
plugged into a power source.
Laying electrical supply
cables
Connection to the mains
power supply
