Strobl Strocomp 433 - Strocomp 433 and 656; Summary

General Technical Description
3 — 3
02_0460_0802GB
Below you will find a summary of the most important components;
t
hese will then be described on the following pages.
1 2 3
8911 1012
54 6
7
View from right
Item Designation
1 Control cabinet
2 Air filter
3 Compressor
4 Safety valve (obscured)
5 Engine
6 Fan
7 Axle and wheels
8 Pressure tank
9 Check valve
10 Dump valve
11 Drain valve
12 External device plug
Continued next page
3.4 Summary
Strocomp 433 and 656
