General Technical Description
3 — 12
02_0463_0802GB
This chapter is intended to help you understand the operational
sequences of the machine so that you can limit the field of the
machine’s applications to suitable areas and avoid errors in
operation.
Maschinenbau Rudolf machines are easy to assemble and operate.
In spite of this, certain precautionary measures must be taken
when
operating the machine to ensure that the wear parts have as high a
life limit as possible.
Strocomp compressors generate compressed air for operating
pneumatic tools.
When combined with a Strobot delivery pump, these compressors
offer maximum performance and guarantee an outstanding spray
pattern.
With a maximum pressure of 10 bar, these compressors offer
maximum performance and guarantee an outstanding spray pattern
when combined with a Strobot delivery pump.
Strocomp compressors have different performance values,
depending on the model.
Please refer to the rating plate, the machine card or the section
on ”Technical data” for the values of the Strocomp compressor.
Powered by the engine, the compressor draws in fresh air through
the air filter, compresses it and the check valve directs the
compressed air into the pressure tank. The compressed air then
flows through the pressure-reducing valve to the connected air hose.
The effective compressed air output depends on the working
pressure.
3.9 Functional descrip-
tion
General description of
the machine
