Transport, Set-up and Connection
4 — 8 04_0131_0802GB
1
3
2
Different models available
Item
Designation
1 Pressure-reducing valve
2 Air hose
3 Air hose connection
Connect the air hose as follows:
Caution
Only couple hose couplings which have been cleaned and have
good condition. Dirty couplings will invariably leak.
" Attach the coupling on the air hose (2) to the air hose
connection (3) on the pressure-reducing valve (1).
" Attach the other end of the air hose to a suitable pneumatic
tool.
Danger
The machine may be operated only with a pneumatic tool
connected!
Caution
Read the information provided by the manufacturer before
connecting ”pneumatic tool” accessories.
4.8 Connecting the
air hose
