General Technical Description
3 — 14
02_0464_0802GB
The machine is controlled and operated via the control cabinet.
H
igh voltage
Work on the electrical system and equipment of the machine must
be carried out by a qualified electrician or by instructed persons
under the supervision and guidance of a qualified electrician and in
accordance with the electrical engineering rules and regulations.
The control cabinet’s wiring, earthing and connections comply with
VDE codes of practice.
Use only original fuses with the specified amperage! The electrical
system can be destroyed by over--rated fuses or bridging.
Continued next page
3.10 Control cabinet
