3.0 CONNECTION
Fig. 6
3.1 Basic connection using an HDMI cable
a. Connect the wall outlet of your cable signal provider to the CABLE IN connector of your receiver using a good
quality coax cable and suitable ‘IEC’ plugs.
b. Connect one end of a good quality HDMI cable to the HDMI output on your receiver and the other end to an
HDMI input of your TV.
c. Connect the supplied power adapter to the receiver at the power supply input. Then plug the power adapter to
a suitable wall outlet.
3.2 Alternatively: Basic connection using a Scart cable
Fig. 6
a. Connect the wall outlet of your cable signal provider to the CABLE IN connector of your receiver using a good
quality coax cable and suitable ‘IEC’ plugs.
b. Connect one end of a good quality Scart cable to the TV SCART connector on your receiver and the other end to
the SCART input of your TV.
c. Connect the supplied power adapter to the receiver at the power supply input. Then plug the power adapter to
a suitable wall outlet.
3.3 Connecting to digital audio amplier
Fig. 6
Connect one end of a good quality HDMI cable to the HDMI output of your receiver and the other end to an HDMI input
of your home theatre or digital amplier. Connect a second HDMI cable to the output of the home theatre or digital
amplier to an HDMI input of your TV. Be sure to select the appropriate HDMI input on the home theatre or digital
amplier to loop the video through to the TV.
Digital HD cable receiver SRT 3030
Supplied by STRONG Austria
CABLE IN
TV SCART
12 V , 1A, max 12W
HDMI
MANUFACTURED UNDER LICENSE FROM DOLBY LABORATORIES.
DOLBY, DOLBY AUDIO AND THE DOUBLE-D SYMBOL ARE TRADEMARKS OF DOLBY LABORATORIES.
HDMI
Cable
SCART
Cable
(optional)
Television
Cable
Broadcast
