Strong SRT 7815 - Basic Connection Using a SCART Cable; Connection to Main Power Supply

12
3.4 Basic connection using a SCART cable
Fig. 8 b
IN LIZENZ VON DOLBY LABORATORIES
GEFERTIGT. DOLBY, DOLBY AUDIO
UND DAS DOPPEL-D-SYMBOL SIND
EINGETRAGENE MARKEN
DER DOLBY LABORATORIES
LICENSING CORPORATION.
a. Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good quality
coax cable and suitable ‘F-connector’ plugs.
b. Connect one end of a good quality Scart cable to the TV SCART connector on your receiver and the other
end to the SCART input of your TV.
c. Plug the power adapter to a suitable wall outlet.
3.5 Connection to main power supply
Fig. 9
IN LIZENZ VON DOLBY LABORATORIES
GEFERTIGT. DOLBY, DOLBY AUDIO
UND DAS DOPPEL-D-SYMBOL SIND
EINGETRAGENE MARKEN
DER DOLBY LABORATORIES
LICENSING CORPORATION.
100 - 240 V AC 50/60 Hz
12 V 1.5 A DC
After all the connections are done you can connect your receiver to power using the supplied external AC/
DC 12Volt 1.5Ampere adapter. Now plug the adapter into the wall socket.
