Struers LectroPol-5 - Technical Specifications; LectroPol-5 Specifications; Noise and Vibration Levels

See LectroPol-5Control unitInstruction Manual.
9 Technical data
9.1 Technical data - LectroPol-5
Subject Specifications
Power supply 50/60 Hz - Max. load: 9.8 A 1 x 100-120 V
50/60 Hz - Max. load: 4.9 A 1 x 220-240 V
Output: Voltage/Current Polishing 0-100 V (1V steps)/6 A
Etching 0-25 V (0.5V steps)/6 A
External etching 0-15 V (0.5V steps)/1.5 A
Dimensions and weight Width 220mm (8.7")
Depth 350mm (13.8")
Height 160mm (6.3")
Weight 6.3 kg (14 lbs)
Safety standards See the Declaration of Conformity
Operating environment Surrounding temperature -50 - 40°C (-58 - 104°F)
Humidity 0-95 % RH non-condensing
Storage and transport
conditions
Surrounding temperature 5 - 40°C (41 - 104°F)
Humidity 0 - 95 % RH non-condensing
9.2 Noise and vibration levels
Noise level A-weighted sound
emission pressure
level at workstations
L
pA
= 55.4 dB(A) (measured value)
Uncertainty K = 4 dB
Measurements made in accordance with EN ISO
11202
Vibration level N/A
30 LectroPol-5
9 Technical data
