EN-8
The Crossre 2 Console
The Crossre2 console is the connection hub for the components of the Crossre2 system. It
generates RF energy for ablation, powers motorized shavers, and provides user controls and
system feedback.
Front Panel
The front console panel features ports for connecting handpieces, controls for adjusting
handpiece settings, and an LCD screen to provide system feedback.
5
7 8
9
3
1 4
6
2
1. Menu Selects menu items
2. Select Selects which device displays on the LCD screen.
3. RF connector
(SERFAS Energy)
Delivers RF energy for ablation handpieces
4. Handpiece connector Powers shaver handpieces
5. Power Powers the console on and o
6. Error indicator Shines red to indicate errors (error details
appear in the LCD)
7. LCD screen Provides system feedback
8. Adjust Adjusts options for connected devices
9. Footswitch connector Connects to the Crossre Footswitch
