Corner Cover Assembly − 26” Litter
117
Item Part No. Part Name Qty.
A 0023−288−000 Hex Washer Hd. Screw 6
B 0023−310−000 Pan Hd. Screw 10
C 0785−010−050 Cover, Hd. End, Bottom Left 1
D 0785−010−051 Cover, Hd. End, Top Left 1
E 0785−010−052 Cover, Hd. End, Top Right 1
F 0785−010−053 Cover, Hd. End, Bottom, Right 1
G 0785−010−058 Cover, Ft. End, Top Right 1
H 0785−010−059 Cover, Ft. End, Bottom Right 1
J 0785−010−062 Cover, Ft. End, Top Left 1
K 0785−010−063 Cover, Ft. End, Bottom, Left 1
L 0785−010−140 Hole Plug 10
M 0785−010−615 End Weldment, Head 1
N 0785−010−122 Foot Board Receptacle 2
