Stryker M Series Maintenance Manual

Brake Rod Assembly
34
Assembly part number 0853−003−201 (reference only)
Item Part No. Part Name Qty.
A 0026−014−000 Slotted Spring Pin 4
B 0026−273−000 Clevis Pin 3
C 0027−020−000 Rue Ring Cotter 3
D 0753−003−015 Brake Rod Nyliner 4
E 0853−003−004 Brake Rod Support 4
F(page 35) Drive Link Assembly 2
G 0853−003−014 Brake Rod 1
H(page 36) Drive Link Assembly 1
J 1210−201−335 Red Brake Label 2
K 1210−201−336 Green Steer Label 2
