Introduction
4
INTRODUCTION
This manual is designed to assist you with the maintenance of the Model SM104 Stretcher. Read it thoroughly
before using the equipment or beginning any maintenance on it.
SPECIFICATIONS
Maximum Weight Capacity 700 pounds
Overall Stretcher Length 84” ( .5”)
Overall Stretcher Width (Siderails Up) 33.5” & 37” ( .5”)
Overall Stretcher Width (Siderails Down) 30.25” & 30.75” ( .5”)
Minimum / Maximum Bed Height 20.75” / 34” ( .5”)
Fowler Angle 0 to 90° ( 3°)
Knee Gatch Angle 0 to 40° ( 1°)
Trendelenburg / Reverse Trendelenburg +16 / −16 ° ( 1°)
Minimum Under Stretcher Clearance 6” (15 cm) nominal
1.75” (4.5 cm) under the hydraulic cyclinders
and 5th wheel
Optional Scale System Weight Operating Range 0 lbs. to maximum capacity of the stretcher
Optional Scale System Accuracy Between 10° Trend & 10° reverse Trend*
2 lbs. of weights below 100 lbs.
2% of weights above 100 lbs.
Optional Scale System Environmental Requirements for
Operation
60_ F − 80_ F
0% − 90% Relative Humidity
* Scale does not meet accuracy claims at Trend angles outside the specified range.
Stryker reserves the right to change specifications without notice.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also
describe potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate
injury to the user or patient or damage to the equipment or other property. This includes special care neces-
sary for the safe and effective use of the device and the care necessary to avoid damage to a device that
may occur as a result of use or misuse.
NOTE
This provides special information to make maintenance easier or important instructions clearer.
